57
Schematic diagram of mechanical control instrument：
The time and speed are shown alternately every 5 seconds
1. Cooling water thermometer
Monitor the engine cooling water temperature, and zone 1 indicates the normal water temperature. When the temperature reaches
zone 2 and 102 ℃, the lamp is on and accompanied by a buzzer.
2. Fuel gauge
Add fuel before the fuel indicator enters the red zone
Preheat
instructions
Fuel
oil
Engine speed
Working hours
Oil pressure
alarm
Voltage
alarm
Water
temperature
alarm
Voltage value
Lights
