Case 435 - Connector - Component Diagram Frame 22 (A.30.A.87 - C.20.F.22); 435, 445, 445 Ct

DISTRIBUTION SYSTEMS - ELECTRICA L POWE R SYSTEM
Connector - Component diagram frame 22 (A.30.A.87 - C .20.F.22)
435, 445, 445CT
Connector 50C
cnh_style-24 1
Cavity Circuit ID
Description
A
12B (T)
To connector 119 pin E
B
13A (T)
To connector 50D pin B
Connector 50D
cnh_style-24 2
Cavity Circuit ID
Description
A
13B (T)
From co nnector 119 pin F
B
13A (T) To connector 50C pin B
1 04/05/2005
A.30.A / 48
