Case 435 - Circuit Breaker - Testing (A.30.A.85 - G.40.A.20); 435, 445, 445 Ct

DISTRIBUTION SYSTEMS - ELECTRICA L POWE R SYSTEM
Circuit breaker - Testing (A.30.A.85 - G.40.A.20)
435, 445, 445CT
NOTE: For wirin g diagram refer to Wiring harness - Electrical schematic frame 01 (A.30.A.88 - C.20.E.01)
N°
Te st Point Expected Result
Other Result (Possible Cause)
1
Termin al for wire 120B (R) to
ground.
12 volts
Check wire 120B (R )
2
Terminal for wire 130A (R) and 130B
(R) to ground.
12 volts Bad 15 ampere circuit breaker.
3
Terminal for wire 170A (R) and 190A
(R) to ground
12 volts Bad 40 ampere circuit breaker.
4
Termin al for wire 180A (R) to
ground.
12 volts Bad 40 ampere circuit breaker.
1 04/05/2005
A.30.A / 101
