DISTRIBUTION SYSTEMS - SECONDARY HYDR AULIC POWER SYSTEM
808L94 2
Female Coupler
1. Outer sleeve 6. Coupler body
2. Inner slee
ve
7. Spring
3. Valve
8. Cap screw
4. Backup washer
9. Collar
5. Seal
10. Fitting
809L94 3
Female Coupler with coupler repair tool installed
1. Valve
7. Cap screw
2. Outer
sleeve
8. Coupl
er repair tool
3. Backup washer 9. Inner sleeve
4. Seal 10. Col
lar
5. Coup
ler body
11. Fitting
6. Spri
ng
85L95 4
Male Coupler
1. Seal
2. Poppet
1 04/05/2005
A.12.A / 12
