3-CONTROLS/INSTRUMENTS
Right-handconsole
1.Storagetray
2.Hornvolumecontrol
Pressingthiskeytogglesthehornalternatelybetween
normalvolumeandreducedvolume.
NOTE:Whentheengineisrestarted,thevolumese-
lectedbeforeshuttingdowntheengineremainsun-
changed.
3.Auxiliary12voltssocket
Thissocketisusedtopowerelectricalequipmentof
12volts.
NOTICE:Itisstrictlyprohibitedtoconnectdevicesof
adifferentvoltage.
4.Optioncontrol(optional)
0454BF85A1
Cupholder
Locatedonthefrontright-handsideoftheoperator'sseat,
thecapholderisdesignedtoholdabeveragecontainer.
Y1MGWJ-001A1
3-62
