Case CX145C SR - Optional Hand Control Levers Configuration

4-OPERATINGINSTRUCTIONS
Optionalhandcontrolleversconguration
TheswitchescanbewiredbyyourCASECONSTRUCTIONDealertocontroleithersinglefunctionordualfunction
hydrauliccongurations.
Themachinecanhavetwotypesofauxiliaryhydrauliccircuits.Onecircuitcanbeusedforsingleowequipment,such
ashydraulicbreakers.Thesecondtypeofcircuitisintendedforusewithsingleowordoubleow(withcontinuous
ow)forusewithdemolitionconcretecrushers,etc.
Theoptionalcontrolbuttonscanbeusedtoactivateandcontrolthesystemformultipurposetoolssuchasacrusher,
nibbler,etc.Additionallytheycanbeconguredtoregulatethepresethydraulicoilowforthespecictoolwhen
pressed.
SeeyourCASECONSTRUCTIONDealerforspecicoptionsandcontrolsforhydraulichammers,breakers,nibblers,
orotherspecialattachments.
Left-handcontrollever
Thelefthandcontrollevercancontrolfourmachineoper-
ationsfortheoperator’sconvenience.
Theradiomuteswitchislocatedontheunderneathside
ofthelefthandcontrollever,whilebutton(3)enablesthe
horn.
Twoadditionalfunctionswitches(1)and(2)areavailable
foroptionaluse.
NZIMV6-002B1
Right-handcontrollever
Therighthandcontrollevercontrolstheengineidlespeed
selector(6).Thisbuttonenablesautomaticengineidle
withoutoperatingthethrottlebutton.
Toselectidlespeed,pressandreleasethecontrolforthe
engineautomaticallytogointoidlespeed.
Themessage“Engineidling”willappearonthedisplay
panel.
Whenthecontrolispressedandreleasedoncemorethe
enginewillreverttoitsoriginalspeedandthemessage
onthedisplaypanelwilldisappear.
Thetwoadditionalbuttons(4)and(5)ontherighthand
controlleverareforoptionaltoolssuchasahydraulic
hammer,breakers,orotherspecialattachments.
FIQCKA-001C2
4-45
