Case CX145C SR - Description of Main Components

1-GENERALINFORMATION
Descriptionofthemaincomponents
TheCX145CSR(standardtypeequippedwithadozerbladeandinoptionwithanoffsetboom)or(LCtype)isa
totallyhydraulicexcavator.Itconsistsofanundercarriagettedwithtracksandaturntablebearingwhichsupports
theupperstructureframe.Theupperstructureframesupportstheattachment,atthefrontendofthemachine,plus
theengine,hydraulicsandcab.Whentheoperatorworksthecontrols,theengine-drivenpumpdelivershydraulicuid
tothecontrolvalves.Thecontrolvalvesdistributethehydraulicuidtothevariouscylindersandhydraulicmotors
employed.Acoolingsystemmaintainsthehydraulicuidatnormaloperatingtemperature.
