Case CX145C SR - Checking the Opening of the Quick Coupler Locking Hook (Optional)

6-MAINTENANCE
Checkingtheopeningofthequickcouplerlockinghook(optional)
WARNING
Improperoperationorserviceofthismachinecanresultinanaccident.
Ifyoudonotunderstandamaintenanceprocedure,ordoubtyourabilitytoperformamaintenance
procedurecorrectly,seeyourauthorizeddealer.
Failuretocomplycouldresultindeathorseriousinjury.
W0157A
Servicespecications
Check:Weeklyandeachtimethequickcouplerisinstalled
ATTENTION:Itisimperativetocarryoutthischeckonceaweekandeachtimethequickcouplerisinstalled.
1.Placetheswitch(1)inunlockingposition.Theaudible
alarmdevicewillsound.(Refertopage3-56).
6B4353DF1
2.Operatethebucketcontroltoretractthecylinderrod
completelyandmaintainthehydraulicpressuresothe
latchinghookretractsandcomesupagainstthelock-
ingbar.
MCHP8N-0072
