4-OPERATINGINSTRUCTIONS
6.Usethecontrolpedaltooperatetheconcretecrusher.
NOTE:Topreventfailureordamagetothetool,make
surethatyouselectthecorrectcircuitcongurationand
owrateandpressureforthetool.
ATTENTION:Inbucketmode,donotcarryoutoperation
usingauxiliaryline.Ifyoudothat,thewarningmessage
“Auxiliaryset-uprequired”willbedisplayedwithintermit-
tentwhistlesound.Stopoperationimmediatelyandcarry
outauxiliaryset-up.
VOHLGR-00522
Proportionalswitchtype
1.Makethenecessarytoolconnectionsandthen,using
ahexagonalwrench,openthesupplyvalveslocated
atthetipofthearm,left-handandright-handside.
VOHLGR-01623
2.Switch(1)locatedontheright-handconsoleupwards,
correspondingtothedemolitiongrab.
Everytimetheswitch(1)ispressed,oneofthediffer-
enttypesofowpatternsrecordedforthepumpcan
beselected.Fortheowandpressuresettingmethod,
refertopage3-27.
VOHLGR-00224
3.Theiconoftheaccessoryassociatedtoeachtypeof
owappearsonthescreen.
0D37C00FZ25
