4-OPERATINGINSTRUCTIONS
Auxiliaryhydrauliccircuitowpatterns
Flowpatternscanbeselectedfromthe20shownbelow.
NOTE:Thenumberofsettingpatternsis10maximum.
1ow2ows
126l/min(27.7UKgpm)252l/min(55.4UKgpm)
117l/min(25.7UKgpm)242l/min(53.2UKgpm)
108l/min(23.8UKgpm)234l/min(51.5UKgpm)
97l/min(21.3UKgpm)223l/min(49.1UKgpm)
85l/min(18.7UKgpm)210l/min(46.2UKgpm)
73l/min(16.1UKgpm)199l/min(43.8UKgpm)
62l/min(13.6UKgpm)188l/min(41.4UKgpm)
51l/min(11.2UKgpm)176l/min(38.7UKgpm)
38l/min(8.4UKgpm)164l/min(36.1UKgpm)
34l/min(7.5UKgpm)160l/min(35.2UKgpm)
Changingtheowpatterns
NOTE:Topreventfailureordamagetothetool,make
surethatyouselectthecorrectcircuitcongurationand
owrateforthetool.
1.Operatetheswitch(1)locatedonthefrontright-hand
switchpaneltodisplaytheowpatterntobechanged.
Everytimetheswitch(1)ispressed,oneofthediffer-
enttypesofowpatternsrecordedforthepumpcan
beselected.
VOHLGR-00230
2.Therecordedvaluecanbeidentiedbythenumber
shownonthescreen,e.g.:
(1)=value1inthetable.
(2)=value2inthetable.
(3)=value3inthetable.
3RW3PD-004Z31
4-43
