6-MAINTENANCE
Offsetboom/arm
34631B7D11
ATTENTION:Ifthefollowinglinkagepointsarenotequippedwithoriginalparts,thesepointsmustbelubricatedevery
50hours.
Every1000hours
Boombottompin:(2)
Boomcylindertoppin:(2)
Armcylinderbottompin:(1)
94E155A812
6-14
