8-SPECIFICATIONS
Arms
2.11m(83.07in)2.50m(98.43in)3.01m(118.50in)
(A)(Maximumdiggingreach)7.94m(312.60in)8.29m(326.38in)8.74m(344.09in)
(B)(Maximumdiggingreachat
groundlevel)
7.78m(306.30in)8.14m(320.47in)8.60m(338.58in)
(C)(Maximumdiggingdepth)5.11m(201.18in)5.51m(216.93in)6.01m(236.61in)
(D)(Maximumdiggingdepthover
alengthof2.44m(96.06in))
4.87m(191.73in)5.29m(208.27in)5.83m(229.53in)
(E)(Maximumdumpheight)6.66m(262.20in)6.94m(273.23in)7.29m(287.01in)
(F)(Maximumworkingheight)9.06m(356.69in)9.34m(367.72in)9.69m(381.50in)
(G)(Minimumattachmentswing
radius)
1.89m(74.41in)1.95m(76.77in)2.33m(91.73in)
(H)(Maximumdiggingdepthona
verticalface)
4.56m(179.53in)4.90m(192.91in)5.28m(207.87in)
(I)(Maximumlengthof
at-bottomedtrench)
2.44m(96.06in)2.44m(96.06in)2.44m(96.06in)
8-11
