8-SPECIFICATIONS
Arms
2.11m(83.07in)2.41m(94.88in)
(A)(Maximumdiggingreach)7.59m(298.82in)7.84m(308.66in)
(B)(Maximumdiggingreachatgroundlevel)7.43m(292.52in)7.69m(302.76in)
(C)(Maximumdiggingdepth)4.91m(193.31in)5.21m(205.12in)
(D)(Maximumdiggingdepthoveralengthof
2.44m(96.06in))
4.59m(180.71in)4.90m(192.91in)
(E)(Maximumdumpheight)6.25m(246.06in)6.43m(253.15in)
(F)(Maximumworkingheight)8.63m(339.76in)8.81m(346.85in)
(G)(Minimumattachmentswingradius)2.22m(87.40in)2.44m(96.06in)
(H)(Maximumdiggingdepthonavertical
face)
3.61m(142.13in)3.91m(153.94in)
(I)(Maximumlengthofat-bottomedtrench)2.44m(96.06in)2.44m(96.06in)
8-13
