Case CX145C SR - Quick Coupler (Optional)

8-SPECIFICATIONS
Arms
2.11m(83.07in)2.41m(94.88in)
(A)(Maximumdiggingreach)7.16m(281.89in)7.41m(291.73in)
(B)(Maximumdiggingreachatgroundlevel)6.99m(275.20in)7.24m(285.04in)
(C)(Maximumdiggingdepth)4.50m(177.17in)4.80m(188.98in)
(D)(Maximumdiggingdepthoveralengthof
2.44m(96.06in))
4.17m(164.17in)4.49m(176.77in)
(E)(Maximumdumpheight)5.87m(231.10in)6.05m(238.19in)
(F)(Maximumworkingheight)8.25m(324.80in)8.42m(331.50in)
(G)(Minimumattachmentswingradius)2.01m(79.13in)2.23m(87.80in)
(H)(Maximumdiggingdepthonavertical
face)
3.25m(127.95in)3.54m(139.37in)
(I)(Maximumlengthofat-bottomedtrench)2.44m(96.06in)2.44m(96.06in)
(J)(Offsetright)1.15m(45.28in)1.15m(45.28in)
(K)(Offsetleft)1.18m(46.46in)1.18m(46.46in)
Quickcoupler(Optional)
Dimensionsneededtotthequickcoupler
Bucketpindiameter65mm(2.6in)
Widthbetweenlugs
220mm(8.7in)
Minimumdistancebetweenbucketcentres
355mm(14.0in)
Maximumdistancebetweenbucketcentres
420mm(16.5in)
ATTENTION:ThequickcouplerdescribedinthismanualisdesignedtobeusedwithCASEbuckets.Thisbeingsaid,
otherbucketsmaybeused,providedthediameterofthepinsandthewidthbetweenthebucketlugsaremodied
tomeetthedimensionsneededtotthequickcoupler(pins,washers,bushings,etc.).ConsultyourCASECON-
STRUCTIONDealer.
Weight
286kg(630.5lb)
Overalldimensions
W4HFRI-0037
(A)860mm(33.9in)
(B)480mm(18.9in)
(C)390mm(15.4in)
8-15
