2-SAFETYINFORMATION
Windshieldlocking
Partnumber:KHP12540
Thisdecalshowsthatthewindshieldmustbecorrectly
lockedinopenposition,inordertopreventitfromtipping.
QA96IC-00121
Functionoftheleversandpedals
Partnumber:
KHP1498(standard)
KHP1484(withright-handoption)
KHP1510(withleft-handoption)
KHP1511(withrightandleft-handoptions)
KHP1572(withdozerbladeifequipped)
KHP1573(withoptionanddozerbladeifequipped)
KHP20950(withoffsetboomifequipped)
KHP20960(withoptionandoffsetboomifequipped)
Thisdecalshowsthefunctionofthetravelcontrollevers
andpedals.
KHP148622
Cigarettelightersocket(24volts)
Partnumber:KHP11590
Thisdecalshowsthelocationandthevoltageofthe
cigarettelightersocket.Itisstrictlyprohibitedtoconnect
devicesofadifferentvoltage.
DEXSB6-00123
Emergencyexit
Partnumber:KHP1247
Thisdecalshowsthelocationandwayhowtousethe
emergencyexit(rearwindow).
Y6JWU1-00124
