3-CONTROLS/INSTRUMENTS
Offsetboompedal(ifequipped)
WARNING
Unexpectedmachinemovement!
ALWAYSlocktheauxiliarypedalswhennotin
use.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0222A
Thispedalisusedtoadjusttheoffsetboom.
(1)Theoffsetboompivotstotheright.
(2)Theoffsetboompivotstotheleft.
(3)Thepedalislocked.(Placetheprotectiononthepedal
tolockit).
(4)Thepedalisunlocked.(Placetheprotectionforwards
tousethepedal).
8C23A63513
877A4C2E14
Footrest
GTQCYL-001C15
Lockingthetravelpedal
Whenthetravelpedalisnotused,itisnecessarytolock
thepedal.
Forlockingthepedal,engagethelockingpin(1)inthe
lockinghole(2).
SNKQ6K-003A16
3-13
