3-CONTROLS/INSTRUMENTS
-If3min.elapsewiththefunctioncancellationlever
closedandwithoutchangingtheenginespeed,"Idle
shutdown"isdisplayedonthemonitor.
-About10sec.after"Idleshutdown"isdisplayed,the
enginestops.
NOTICE:Toprotecttheengine,atleast3min.ofidling
isrequired.
NOTE:Torestarttheengine,rstsettheignitionkeyto
“Off”,andthenstarttheengine.
•
Inautoidlingandautostop,“Auton/min”and"Auto
stop"aredisplayed.
NOTE:Iftheyarestillselectedwhentheengineis
stopped,theywillremainactivewhentheengineis
restarted.
8.Menuscreendisplayswitch
Pressthisswitchtodisplaythemenuscreen.
Themenucontainsthefollowingitems.
Language
Brightness(day)
Brightness(night)
Fuelconsumptionindicator
Maintenanceinformation
Clockadjust
Auxiliaryhydraulics
Camerasetting
Usetheswitchshowninthediagramtoselectora
changeamenuitem.
MUC8LU-0262
Refertopage3-27foruse.
9.Cameradisplayswitch
Pressthisbuttontoswitchbetweenthemachine
informationscreen,machineinformation+camera
jointdisplay,andcameraimageindependentdisplay
(mode,travelmode,clockandwarningonly).
•Mode1:Normalscreen
MUC8LU-003Z3
Machineinformationscreen
•Mode2:Camerascreen
3PZT8U-003Z4
Machineinformationpluscamerajointdisplay
•Mode3:Camerascreenwithoutindicators
3PZT8U-004Z5
Cameraimageindependentdisplay(mode,travel
mode,clockandwarningonly)
The3typesaboveareavailableforselection.
10.Hourmeterselect/backmonitorselectswitch
Intheinformationscreen,hourmeterselectisen-
abled.
"Trip"control(partialhourmeter)
Usedtocalculateaspecicoperationtime.
Pressthecontroltosetthehourmeterdisplayto0
anddisplaythe"Trip"message.
Releasethecontrol.
Afterabout1min.,the"Trip"displaydisappearsand
thenormalhourmeterdisplayreturns.
Toviewthespecicoperationtime,pressthecontrol
andreleaseitimmediately.
