231
2. If you require a password to set in the screen appeared after clicking Backup now button,
enter a password (see note below) in Password field and then press F3 key (= Tab key) to
confirm. Enter the same password in Confirm Password field and then press F2 key (=
Back Tab keys). Click Yes button to complete the entering of password. Otherwise No
button to return to the previous screen.
Note:
To enter a password, change the mouse emulation mode to the numeric enter mode by
pressing Fn key first and then 4 key. To return to the mouse emulation mode, sequentially
press the same keys again.
3. If you choose Yes button in the step above, Backup in Progress screen appears and the
backup process is initiated. While the backup continues, do not operate any key on the
keyboard or on the sides.
Figure 4-27
4. When the backup is complete, a buzzer sounds in a short period indicating the completion.
Click OK button in the message screen.
Figure 4-28
