Data Receiver Data Sender Operation
(External Device) (This Instrument)
SBS(HBR) -----> Session Start
Request
<----- ACK Acknowledge
HBR -----> Send Request (Start
Sub Session)
<----- HBS Send Packet
ACK -----> Acknowledge
<----- HBS Send Packet
ACK -----> Acknowledge
<----- HBS Send Packet
ACK -----> Acknowledge
:
Send Other Packet
:
ACK -----> Acknowledge
<----- ESS End Data (End Sub
Session)
:
Other Sub Session
:
EBS -----> End of Session
18.3.8 Example: Data send to Instrument from external device
Data Sender Data Receiver Operation
(External Device) (This Instrument)
SBS(HBS) -----> Session Start
Request
<----- ACK Acknowledge
HBS -----> Send Packet
<----- ACK Acknowledge
HBS -----> Send Packet
<----- ACK Acknowledge
HBS -----> Send Packet
<----- ACK Acknowledge
:
Send Other Packet
:
ESS -----> End of Data
:
Other Sub Session
:
EBS -----> End of Session
57

Casio XW-P1 Specifications

General

Polyphony	64 notes
Arpeggiator	Yes, 6 types
Power Supply	D batteries x 6, AC Adapter
Dimensions	95.7 x 39.7 x 11.1 cm
Weight	13.2 lbs
Effects	Reverb, Chorus, Delay, Distortion, Rotary Speaker
Display	LCD
User Tones	100
Inputs/Outputs	USB
User memory	100 user tones
Controllers	Pitch Bend Wheel, Modulation Wheel
Inputs	Line In
Outputs	1/4" L/Mono, R output
Keyboard	61 keys
Connections	USB
