18.3.9 Example: Session Generating a Timeout Error
Data Receiver Data Sender Operation
(External Device) (This Instrument)
SBS(HBR) -----> Session Start
Request
Interval *Note1
ERR(Time Out Error) -----> Timeout Error
<----- ACK Acknowledge
HBR -----> Send Request
(Optional)
<----- HBS Send Packet
ACK -----> Acknowledge
Interval *Note1
ERR(Time Out Error) -----> Timeout Error
Interval *Note1
ERR(Time Out Error) -----> 2 consecutive
timeout errors
(Note2)
<----- HBS Acknowledge
Interval *Note1
<----- ERR(Time Out Error) Timeout Error
ACK -----> Acknowledge
<----- HBS Send Packet
:
Note1 : Interval that exceeds the time stipulated by Handshake Max Interval explained under “20.2 System Exclusive
Protocol Parameter”.
Note2 : Number of retries that exceeds the retries stipulated by Handshake Max Retry explained under “20.2 System
Exclusive Protocol Parameter”.
18.3.10 Example: Session Generating a Format Error
58
