CASTLE S SERIES CONTROLLER – TECHNICAL OPERATION GUIDE
Access Level
Press ‘6’ to select [6-Acc Lvl] menu from System Menu.
This menu item sets the Access Level for the card user.
When user select this menu item, controller will display the following: -
There is 100 Access Level setting. AccessLevel_00 and AccessLevel_01 are pre-fixed sets, cannot
be changed. Only from AccessLevel_02 to AccessLevel_99 can be set by the user.
User can use ‘0’ to ‘9’ to select which Access Level he/she wants to update.
For example: -
To set the AcessLevel_77, press ‘7’ for twice, the LCD will display as follow: -
dd => day mm => month
yyyy => year
After that it will prompt the user to enter the data. The display as following: -
Digits in the ( ) bracket are under focus.
This is the start of the Expiry Date setting. The earliest Start Date is 01/01/1998.
After keying the Start Date, the display will be changed as following: -
Digits in the ( ) bracket are under focus.
This is the end of the Expiry Date setting. The latest End Date is 31/12/2030.
After keying the End Date, the display will be changed as following: -
00-99 is available. This option lets user to set the TimeZone for the card user. The card user only can
access the door within the TimeZone.
Repeat the step to proceed to Door_2_TZ (2s), Door_4_TZ (4s) or Door_8_TZ (8s).
Access Level Door 1 (Tz) Door 2 (Tz) Door 3 (Tz) Door 4 (Tz)
Default 00 00 00 00 00
Default 01 01 01 01 01
02 01 02 00 00
03 02 00 00 00
04 03 03 03 03
CASS TECHNOLOGY SDN BHD(338857-X) 24
