CASTLE S SERIES CONTROLLER – TECHNICAL OPERATION GUIDE
Changing Password
Press ‘1’ to select [1-CH Pass] menu from the Maintenance Menu.
This menu item is to change the Programming password. The user can only change the
password of their level. To change the password, user just keys in the new 6 digits password.
‘0’ to ‘9’ are available.
Set String
Press ‘2’ to select [2-Set Str] menu from the Maintenance Menu.
This menu is to change the display message at the controller LCD display. The default is
Cass Technology.
To enter numbers, press the ‘0’ to ‘9’ keys.
To enter the ‘A’ to ‘Z’ alphabets, press one of the ‘A’, ‘B’, or ‘C’ keys followed by the ‘0’ to
‘9’ keys. The ‘0’ to ‘9’ keys has the alphabets labeled at the bottom of the key.
· Pressing ‘A’ followed by the numbers key will select first alphabet labeled under this
key.
· Pressing ‘B’ followed by the numbers key will select second alphabet labeled under this
key.
· Pressing ‘C’ followed by the numbers key will select third alphabet labeled under this
key.
Testing
Press ‘3’ to select [3-Test] menu from the Maintenance Menu.
Then the controller will display the following: -
CASS TECHNOLOGY SDN BHD(338857-X) 35
dd/mm DDD hh:mm:ss
1-Test kpd 2-Test WD
dd/mm DDD hh:mm:ss
2-Test WD 3-Test IP
dd/mm DDD hh:mm:ss
3-Test IP 4-Test OP
dd/mm DDD hh:mm:ss
5-Rd Stat 0-Main
dd/mm DDD hh:mm:ss
4-Test OP 5-Rd Stat
