CASTLE S SERIES CONTROLLER – TECHNICAL OPERATION GUIDE
Setting Time Zone
Time Zone # SUN MON TUE WED THU FRI SAT HOL1 HOL2
Time Zone #01
01 01 01 01 01 01 01 01 01
Time Zone #02
00 02 02 02 02 03 04 00 00
Time Zone #03
00 02 00 02 00 02 00 00 00
Each entry in the Time Zone setting above refers to the TimeSet no.
In the table above,
a. The Time Zone #01 specifies that the card will use TimeSet #01 everyday where TimeSet #01 is
00:00 to 23:59 (24 hours access).
b. The Time Zone #02 specifies that the card will use TimeSet #00 on Sunday and Holidays (non-
access at all), TimeSet #02 on Monday till Thursday (08:00 to 12:30, 13:30 to 18:00), TimeSet
#03 on Friday (08:00 to 12:00, 15:00 to 18:00) an TimeSet #04 on Saturday (08:00 to 13:30).
c. The Time Zone #03 specifies that the card will use TimeSet #00 on Sunday, Tuesday, Thursday,
Saturday and both two holidays (non-access at all) and TimeSet #02 on Monday, Wednesday
and Friday.
Typically you can assigned the card of
a. Manager/director with TimeZone #01,
b. Normal staff with TimeZone #02 and
c. Cleaners with TimeZone #03.
Since the Castle-S controller controls 8 doors, you need to specify the TimeZone Setting of a card
for each door.
Press ‘5’ to select [5-Tzone] menu from System Menu.
This menu item sets the TimeZone database. When user select this menu item, controller will display
the following: -
There are 100 time zones available. TimeZone_00 and TimeZone_01 are pre-fixed sets, cannot be
changed. Only from TimeZone_02 to timeZone_99 can be set by the user.
User can use ‘0’ to ‘9’ to select which TimeZone he/she wants to update.
For example: -
To select TimeZone_11, press ‘1’ for twice, the LCD will display as follow: -
This display shows the Timer_01 to be used on Sunday for TimeZone_11. User can change the timer by using
‘0’ to ‘9’ keys or accept without changes by pressing the ‘ENT’ key. To clear the Timer, set the Timer to ‘00’.
Repeat the step to proceed to MON, TUE, WED, THU, FRI, SAT, HOL_1 AND HOL_2.
CASS TECHNOLOGY SDN BHD(338857-X) 23
