CASTLE S SERIES CONTROLLER – TECHNICAL OPERATION GUIDE
Digits in the ( ) bracket are under focus.
Proceed in the same way to change Hour and Minute. Once user has completed changing Minute, the
system clock will be updated.
Door Setting
Press ‘2’ to select [2-Door] menu from System Menu.
This menu item allows user to set the door setting. To set the specified door, user has to enter the
number of door (1-2 for 2s series, 1-4 for 4s series, 1-8 for 8s series). To set the other door, user has
to press the ‘2’ again at System Menu to enter to Door Setting Mode.
When the user select this menu item, the controller will step through each of the Door Setting. The
key usage under this menu is listed below: -
Key Function
0 – 9 Set the digit
ESC Skip the setting
ENT/D Accept the setting
For ON/OFF value entries, use the ‘0’ key to toggle the value.
a. Lock Release Time
A value of 00-15 is allowed. This value determines the amount of time (in seconds) that the
electric door-lock is activated after a valid user card has been swiped. If the door is not opened
within this time period, the door will be deactivated. The default value is 05 seconds.
b. Door Open Time
A value of 00-30 is allowed. This value determines the amount of time (in seconds) that the door
takes to close. If the door is left opened for longer than this time period, the buzzer would sound.
The default value is 10 seconds.
c. In Location Code
A value of 00-99 is allowed. This value determines the door In Location Code of the Door. This
setting will be used when the Anti-PassBack Mode at the Parameter Menu is ON.
CASS TECHNOLOGY SDN BHD(338857-X) 16
dd/mm DDD hh:mm:ss
Hr(09) MIN[54]
dd/mm DDD hh:mm:ss
In Loc Code [ 00 ]
dd/mm DDD hh:mm:ss
Door Open Time [ 10 ]
dd/mm DDD hh:mm:ss
Lock Rel Time [ 05 ]
