see label 1 on the machine
Cutting capacity:
Maximum width:
Maximum height of moulding:
3500 tr/mn for 60Hz and 2800 tr/mn for 50Hz
Maximum length to be cut:
230v MONO-30 A /
230v TRI-16 A /
400 TRI-10 A
3 x 2.5 HO7RNF 3G2.5 (230v MONO) /
4 x 1.5 HO7RNF 4G1,5 (230v and 400 v TRI).
2 Motors, power: (conformity EN 30204)
Dust collector type in accordance with standards:
To ensure correct extraction of the dust, suction flow should be:
Thermal Protection/Electrical socket:
8A for 220V TRI / 5 A for 380V TRI
4 bars mini / 6 bars maxi
Maximum air consumption for 700 cuts per hour:
2.5 Nl per cycle at 6 bar
Noise: (ear protections must be wear) Noise information: Measured
according ISO 7960-1995 standard).
Operating condition of noise measurement:
1 Metering at operator position, not cutting, dust collector off: 81dB (A )
9 Metering at one meter not cutting, dust collector on / reference surface: 85dB (A )
9 Metering at one meter, machine in cutting process, dust collector on / reference surface: 89dB (A )
These values are measured values; they are not necessarily showing safe working conditions.
Even if there is a correspondence between emission and exposure level, these measures can’t be used to determine the necessary
protections to wear.
Parameters such as workshop configuration, other noise sources and machinery or other manufacturing process can affect the
exposure noise level of the operator.
Also allowed exposure level can fluctuate from a country to another one.
However, these values will help the user to evaluate the risk of using this machine.
Measurement report: BUREAU VERITAS N° 6164860-1/1-Z49SOP.
