6 / SETTING UP THE MACHINE
There must be sufficient clearance around the machine to allow free
movement and access for maintenance.
The CS969 saw must be placed on a stable and generally flat floor.
Floor must be able to support load of 1250 Kg/m² and 315 Kg for
each foot.
Before making any electrical or pneumatic connections, level the
machine by means of the adjustable feet.
Use a 24-mm open-end spanner for locking nut (CE) and a 12-mm open-end spanner
for base (B).
Tighten locking nut (CE) firmly after adjustment and levelling.
As the work surface is 900 mm from the floor, it may be necessary to install a platform
for operators of short stature.
Sufficient space must be reserved around the machine to ensure a freedom of
movement and good acces for maintenance (see next page)
When installing the machine, make sure the floor is leveled and can support the weight of the machine.
The machine must be installed in a dry and temperate place. Choose a location where light will be sufficient to
ensure a comfortable use of equipment.
