Activate clamp by pressing button 6 (see table on page 25). Bring the mobile Stop in contact with the moulding, and block it. Release
button 6 to deactivate the clamp.
Release the cursor from under the moulding.
The measurement at the bottom of rebate is completed.
7.F.b External measurement
Release locking handle. Slide it on the rule until it reaches the required measurement.
Be sure to measure using the external rule in relation to the punch mark on the mobile stop.
Block it. The external measurement is complete.
RETRACTABLE STOP
7.G.a Storing a second cutting point in the memory
FOR THE REBATE MEASUREMENT, USE THE SAME
PROCEDURE AS FOR THE MOBILE STOP (PAGE 31).
FOR THE EXTERNAL MEASUREMENT, USE THE SAME PROCEDURE
AS FOR THE MOBILE STOP (PAGE 31) BUT USE THE INTERNAL RULE
