BILL OF MATERIAL - NOMENCLATURE CS969.
REFERENCE
QTY/unit
DESIGNATION
DESCRIPTION
CS969
1
U
SCIE DOUBLE LAME 400/460 V 50/60HZ TRI PNEUMATIQUE
CS 969 DOUBLE MITRE SAW 400/460V THREE-PHASE
CS969BASE2
1
U
SCIE DOUBLE LAME BASE 2 CARTERS PROFILS ALU
Z10435
2,00
m
CABLE 1 X 1.5 VERT JAUNE
Z1044
3
U
VIS AUTOTARAUDEUSE 4 X 13 ZINGUEE
AUTO TAPING SCREW 4 X 13
Z1379
1,00
m
PROFIL CAOUTCHOUC NOIR (LE M)
BLACK RUBBER PROFILE
Z1409
2
U
ECROU NYLSTOP M 3
NUT NYLSTOP 3
Z1417
2
U
ECROU NYLSTOP M6
NUT NYLSTOP 6
Z15218
1
U
S/E CABLAGE PLATINE CS969 BASE
SUB ASSY CS969 WIRING BOARD
Z1553
15,00
m
CABLE 4 X 1.5 HO7RNF 4G1.5
CABLE 4 X 1.5 HO7RNF 4G1.5
Z1602
2
U
RONDELLE M D: 3
WASHER M 3
Z1805
1
U
PRESSE ETOUPE N° 9
STUFFING BOX N°9
Z1808
2
U
SERRE CABLE D. 6
CLAMPING RING D.6
Z1847
2,00
m
GAINE SPIRALEE (M)
SPIRALE SHEATH
Z19863
6
U
COSSE BLEUES A SERTIR RONDE ISOLEE D4 FIL2.5 A 4
BLUE ROUND CRIMPS ø4
Z23790
1
U
ETIQUETTE ATTENTION NE PAS BRANCHER L' AIR (VOIR
COMMENTAIRE)
CAUTION
Z26007
1
U
CARTER ARRIERE
BACK COVER
Z27620
1
U
SUPPORT RALLONGE D
EXTENSION SUPPORT RIGHT
Z27880
1
U
SUPPORT RALLONGE G
EXTENSION SUPPORT LEFT
Z28270
1
U
S/E TOLERIE CS969 PROFILES ALU ET ACCESSOIRES
SUB ASSY CS969 ALU PROFILE & ACCESSORIES
Z28299
1
U
S/E TABLE GAUCHE ALU
SUB ASSY ALU LEFT TABLE
Z28378
1
U
S/E MICRO-CONTROLEUR ATMEGA 328 PU + PROGRAMME CS969
MICRO-CONTROLEUR
Z28587DETAIL
1
U
S/E PROFILS ALU CS969 DETAIL
SUB ASSY CS969 ALU PROFILE
Z28593DETAIL
1
U
S/E TOLERIES CS969 DETAIL
SUB ASSY CS969 SHEET METAL
Z28595
1
U
S/E BASE SCIES CS969 2017
SUB ASSY CS969 SAW BLADE BASE
Z28605
1
U
S/E PNEUMATIQUE CS969 2017
SUB ASSY CS969 PNEUMATIC
Z28690
1
U
S/E TABLE DROITE ALU
SUB ASSY ALU RIGHT TABLE
Z294
2
U
VIS CHC 3 X 30
SCREW CHC 3 X 30
Z336
2
U
VIS CHC M6-30 - 8.8
SCREW CHC 6 X 30
Z3935
6
U
RONDELLE L5
WASHER L D: 5
Z694
1
U
AMPOULE 48V -3W
BULB
Z8043
3
U
COSSE A SERTIR D: 8
WIRE END D: 8
Z8257
1
U
COSSE A SERTIR D: 4.3
WIRE END D: 4.3
Z9133
4
U
RONDELLE L D: 3
WASHER L D: 3
Z9596
1
U
COLLIER COLSON 4.6 X 200 NOIR
TIE RAP COLSON 4.6 x 200 NOIR
Z15685
1
U
S/E EMBALLAGE CS960 / CS969
SUB ASSY PACKAGING CS960/969
Z15767
1
U
CAISSE EXPAK 1450 X 1150 X 1390 X 6 INTER + CALAGES
CRATE EXPAK 1450 X 1150 X1390 X6 INTER + SPACERS
Z16037
1
U
S/E BOITE ACCESSOIRES CS 960 / CS969
ACCESSORY BOX CS 960 / CS969
Z26915
2
U
ETIQUETTE SECURITE GANT
GLOVE SAFETY LABEL
Z26916
1
U
ETIQUETTE SECURITE BRUIT + LUNETTES
NOISE & GLASSES SAFETY LABEL
Z26917
1
U
ETIQUETTE SECURITE POUSSIERE
DUST SAFETY LABEL
Z26918
1
U
ETIQUETTE SECURITE LIRE LE MANUEL
SAFETY LABEL
Z26969
1
U
ETIQUETTE SECURITE MISE A LA TERRE OBLIGATOIRE
MANDATORY GROUNDING SAFETY LABEL
Z26970
1
U
ETIQUETTE SECURITE DEBRANCHER AV D'EFFECTUER UNE
OPERATION DE
UNPLUG BEFORE SAFETY LABEL
Z2798
2,00
m
PAPIER ANTIROUILLE (LE KG) VOIR COMMENTAIRES
RUST PROTECTION PAPER
Z9160
1
U
ETIQUETTE SUPPORT IDENTITE MACHINES
ETIQUETTE SUPPORT IDENTITE MACHINES
Z9161
1
U
PLANCHE D'ETIQUETTES SCIES
PLANCHE D'ETIQUETTES SCIES
Z1602
2
U
RONDELLE M D: 3
WASHER M 3
Z19880
1
U
ETIQUETTE TENSION 380 V TRI ADHESIVE
