Hardware Setup 2-11
CONFIGURATION JUMPER JP1
The table below describes the features of JP1.
Jumper Standard Running Mode
JP1-1 Overload Disable
JP1-2 Reserved
JP1-3 Self-Test and EEPROM
JP1-4 Baud Rate
JP1-1, Plunger Overload Detection
This jumper position allows enabling or disabling of plunger overload detection. There
are two possible settings:
JP1-1 removed Plunger overload detection enabled (default setting)
JP1-1 installed Plunger overload detection disabled
JP1-2, Reserved
JP1-3, Self-Test and EEPROM AutoStart
When JP1-3 is in and the address switch is set to position “F,” the self-test diagnostic
program will be activated. For more information on using the address switch and the self-
test, see “Address Switch Settings” in this chapter.
When the address switch is in any position other than “F,” the autostart mode of the
EEPROM can be activated or inactivated.
JP1-3 removed EEPROM, self-test disabled (default setting)
JP1-3 installed EEPROM self-test enabled
JP1-4, Baud Rate
This jumper position is used to select the baud rate for the RS-232/RS-485 version of the
XP 3000. There are two baud rates to select from:
JP1-4 removed 9600 baud (default setting) (100K baud for CAN)
JP1-4 installed 38400 baud (125K baud for CAN)
