XP 3000 Physical Specifications E-1
E - XP 3000 Physical Specifications
Table E-1. XP 3000 Physical Specifications
Dimensions
Height 5.0 in (127 mm)
Width 1.8 in (45.7 mm)
Depth 4.5 in (114.3 mm) from front panel to connector
Weight 2.5 lbs (1.1 kg)
Resolution
3000 steps (24000-step capability when using microstep-enabled
firmware)
Plunger Drive
Principle Rack and pinion drive with quadrature encoder and home flag
Travel 30 mm
Plunger Speed Variable from 1.2 secs/stroke to 20 min/stroke
Syringes
Sizes
50 µL, 100 µL, 250 µL, 500 µL, 1.0 mL, 2.5 mL and 5.0 mL
Barrel Material Borosilicate Glass
Plunger Material Stainless Steel
Seal Material Virgin Teflon (PTFE, TFE)
Precision
<0.05% CV at full stroke (250 µL syringe and above)
<0.1% CV at full stroke (50 µL and 100 µL syringe)
Accuracy <1% at full stroke
Valve Drive
Turn time
≈250 ms between adjacent ports (3-port valve)
Drive Stepper motor with optical encoder for positioning feedback
Valves
Plug Material Virgin Teflon
Body Material Kel-F
Fittings 1/4-28 tubing and syringe fittings
M6 or 1/4-28" syringe fitting
Valve Positions 120° 3-port, 3-port Distribution, T-Valve, Y-Block
Fluid Contact Glass, Kel-F, Teflon
Power Requirements
Voltage 24VDC + 10%
Current 1.5 A (peak)
