CAVRO XP 3000 - Page 74

Software Communication 3-38
Speed codes, the Hz (half-steps/second) equivalent, and seconds per stroke are listed
below. Seconds/stroke values are based on default ramping.
Speed Code Pump Freq (Hz) Seconds/Stroke
1 5600 1.2
2 5000 1.3
3 4400 1.4
4 3800 1.6
5 3200 1.9
6 2600 2.2
7 2200 2.6
8 2000 2.9
9 1800 3.3
10 1600 3.7
11 1400 4.3
12 1200 5.0
13 1000 6.0
14 800 7.5
15 600 10.0
16 400 15.0
17 200 30.0
18 190 31.0
19 180 33.0
20 170 35.5
21 160 37.5
22 150 40.0
23 140 43.0
24 130 46.0
25 120 50.0
26 110 55.0
27 100 60.0
28 90 67.0
29 80 75.0
30 70 86.0
31 60 100.0
32 50 120.0
33 40 150.0
34 30 200.0
35 20 300.0
36 18 333.3
37 16 375.0
38 14 428.6
39 12 500.0
40 10 600.0
