Advanced Setting
Approach speed
Approach speed
|||||||||||||||||......................5
It’s possible to change the approach speed during the nal closing.
This can be usefull if the door nds some friction in the last approaching motion where is
searching for the close position.
Default value = 5.
18)
Advanced Setting
Obst. detection %
Obst. detection %
|||||||||||||||||......................2%
It’s possible to change the percentage of the complete door trip after which the door
doesn’t detects an obstacle but assigns the stop to the close position.
Default value = 2%
19)
Advanced Setting
Min Open Speed
Min Open Speed
|||||||||||||||||......................5
20)
It’s possible to change the approach speed during the OPENING.
This can be usefull if the door nds some friction in the last approaching motion where is
searching for the open position.
Default value = 5.
Advanced Setting
% Min Open Speed
% Min Open Speed
|||||||||||||||||...................2%
It’s possible to change the percentage of the complete open trip after which the keeps
the speed at the value set with the parameter “Min Open Speed”.
Default value = 2%.
21)
Advanced Setting
O.D. Cycle
O.D. Cycle:
Fast
22)
It’s possible to set the type of cycle after an obstacle detection:
FAST : the door keeps the regular speed after the detection of an obstacle
SLOW : the speed of the door after an obstacle is slow.
Advanced Setting
OD on Closing
OD on Closing
Reopen
16)
After the detection of an obstacle during the closing the door will react in different way,
according to the following settings:
• Reopen : The door reopens and after the pause time recloses
• Stop & Wait : The door stops and after the pause time recloses
• STOP : The door stops: waits for a command to reopen and for a further
command to reclose.
Advanced Setting
Test FTC
ENABLED /
DISABLED
It’s possible to disable the test on the re-open photocell FTC:
ATTENTION!!: If the test is DISABLED the operator must work in Low Energy Mode
otherwise it doesn’t operate in compliance with the Standard EN16005.
23)
Advanced Setting
Test FTC-S
ENABLED /
DISABLED
24)
It’s possible to disable the test on the stop photocell FTC-S:
ATTENTION!!: If the test is DISABLED the operator must work in Low Energy Mode
otherwise it doesn’t operate in compliance with the Standard EN16005.
Advanced Setting
Test FTC Fail
STOP /
LOW ENERGY
In case of malfunction of the safety photocells FTC it’s possible to set the operating
mode: STOP / motion in LOW ENERGY
25)
Advanced Setting
Test FTC-S Fail
STOP /
LOW ENERGY
26)
In case of malfunction of the safety photocells FTC-S it’s possible to set the operating
mode: STOP / motion in LOW ENERGY
Advanced Setting
Low Energy
Diameter (m)
|||||||||||||||||......................1,2
The sw calculates the minimum opening/closing time when the malfunction mode is set
at Low Energy, according to the doorset diameter ( in m) and weight ( in Kg ).
27)
Advanced Setting
Low Energy
Weight ( Kg )
|||||||||||||||||...................120
Sets the doorset weight in Kg.
