15
The NAV key cycle is as follows:
H035 From Standby
NA 1 Selects the NMEA Input (1-3)
AUTO Automatic Waypoint Sequence Display, or
not auto Manual Acceptance Sequence Display
}14 Cross Track Error Display
N226 Selects Navigator Control
To exit Navigator Control, at any time.
2.3 Selecting NMEA Input
On the first press of the NAV key, the NMEA Input is displayed.
NA1 NMEA Input PL11 in the 930609 Pilot Computer
Additional NMEA Inputs are only available with a 930619 Pilot
Computer, to change the NMEA Input press the ADJ key.
NA2 NMEA Input PL17 in the 930619 Pilot Computer
NA3 NMEA Input PL16 in the 930619 Pilot Computer
C775 Only when a ChartPilot 775 is connected to a 930619 Pilot
Computer is “C775” displayed.
or
E
D
E
E
D
E
