PROPILOT 700
22
4.1 Installation Procedure
It is important to read the documentation for each unit prior to
commencing installation.
1. Refer to the 930 609/619 Pilot Computer Manual for:
•A step by step installation procedure for connecting
the ProPilot 700 system into the Pilot Computer.
• Connecting Cetrek peripheral equipment.
• Setting the Jumpers and Links.
The 700 does not have an On/Off switch,
therefore:
• Systems with only 700s (and/or 770s), must
move J7 to the ‘Auto Power On’ position.
• If the 700(770) is used as a second station with
a control head that has an on/off switch, J7
must not be moved, the other control head
must be used to turn the autopilot on or off.
2. To install the ProPilot 700, refer to sections 4.3 to 4.5.
3. Once the ProPilot 700 system’s mechanical installation is
complete, carry out:
• Dockside Settings (section 5, steps 1 - 5), and
• Sea Trials (section 6, steps 6 - 9) to configure the pilot to
your vessel, then
• Pilot Configuration (section 7) to configure the pilot with
the peripheral equipment connected to your system.
4.2 ProPilot 700 Specifications
Voltage: Nominal 12V / 24V DC
Operating Temperature: 0º to +55º C
Cable (510529): 6 way x 6 metres (Screened)
Dimensions: 125 mm x 125 mm x 36 mm
Weatherproof
