25
5. Dockside Settings
Having completed the mechanical installation of the system, the
next step is to configure the ProPilot 700 for the characteristics of
your boat, because no two vessels are quite the same.
In order to use the pilot successfully, it is MANDATORY that you
carry out the Vessel Type and the Rudder Settings Routine.
Press and hold the ADJ key for three seconds until “CONF” is
displayed. Press the ADJ key to display the next option in the
menu. If you press the ADJ key after “RSET” you will return to
the beginning of the menu cycle “CONF”.
To return to the heading display, press the OFF key, and to return
to the same Pilot Configuration option press the ADJ key.
To exit the Pilot Configuration Menu press and hold the ADJ key
for three seconds, until a Sea State Adjustment option is displayed.
Installation Steps
1 Powering Up for the First Time
2 Vessel Type
3 Rudder Settings Routine
4 Align Compass
5 Checking the settings
5.1 Powering up for the First Time
Ensure that all units are installed correctly, that the correct size fuses
or circuit breakers are fitted and that the ship’s batteries are
adequately charged. Finally check that all the system connections
are correctly made before switching the power on.
Return the rudder to the midships position.
Switch the ProPilot 700 supply ON, if the steering operates,
switch off at once and re-check the connections.
If all is correct the ProPilot 700 displays a start-up sequence:
8888 Displays all the segments of the LCD,
Sn** Software Version Number,
Step 1
