PROPILOT 700
26
P700 Pilot Control Type,
tESt then Self test completed successfully.
H*** The vessel’s heading is now displayed.
Check the Rudder Position Display
Press the ADJ key repeatedly until the Rudder Position display reads
“Pr00” or “Sr03” (the figure is the rudder's angle in
degrees from midships).
With the rudder at midships, if the figure shown is 5 degrees or
less, it will be corrected during the Rudder Settings Routine. If over
5 degrees, mechanically readjust the Rudder Feedback Unit (refer to
the Installation Instructions).
Depending on how the Rudder Feedback Unit is mounted, the
direction of the pilot’s rudder information may be reversed, this will
be corrected during the Rudder Settings Routine.
5.2 Vessel Type Configuration
CONF Press and hold the ADJ Key until “CONF” is displayed. Press
the key to display the current Vessel Type.
In the Autopilot’s memory there are 4 pre-set vessel type
configuration settings. Press the or key to scroll through the
vessel types, the setting displayed will be the one used.
PLAN PLANING hull
SAiL SAILING vessel
diSP DISPLACEMENT hull
SdIS SEMI-DISPLACEMENT hull
The “SAiL” setting enables the Tack function, in Auto Mode.
5.3 Rudder Settings Routine
ruddEr Press the ADJ key, the ProPilot 700 will display
SEttINGS “ruddEr SEttinGS”
Step 2
Step 3
