Introduction
Voltage Selection
Voltage Selection
120/240V single and 3 phase dedicated sku
480V 3 phase dedicated sku
208V 3 phase Via accessory step down transformer
600V 3 phase Via accessory step down transformer
Model Electrical Ratings
Model Operator Type Electrical Rating Cycle Max. Door Weight
JDC7S1BMC
Jackshaft
non-hoisted
Operators
120Vac, 5A, 1PH; 240Vac, 2.5A, 1PH/3PH**
Standard
Cycle
700 lbs.
JDC7S4BMC 480Vac, 1.25A, 1PH/3PH**
JHDC7S1BMC
Hoist Operators
120Vac, 5A, 1PH; 240Vac, 2.5A, 1PH/3PH*
Standard
Cycle
700 lbs.
JHDC7S4BMC 480Vac, 1.25A, 1PH/3PH*
JHDC12S1BMC 120Vac, 9A, 1PH; 240Vac, 4.5A, 1PH/3PH*
1200 lbs
JHDC12S4BMC 480Vac, 3A, 1PH/3PH*
JHDC12X1BMC 120Vac, 10A, 1PH; 240Vac, 5A, 1PH/3PH*
Extended
Cycle
JHDC12X4BMC 480Vac, 3.5A, 1PH/3PH*
JHDC22X1BMC 120/240 single, 3 phase*
2200 lbs
JHDC22X4BMC 480V 3 phase*
TDC7S1BMC
Trolley
Operators
120Vac, 5A, 1PH; 240Vac, 2.5A, 1PH/3PH*
Standard
Cycle
700 lbs.
TDC7S4BMC 480Vac, 1.25A, 1PH/3PH*
TDC12S1BMC 120Vac, 9A, 1PH; 240Vac, 4.5A, 1PH/3PH*
1200 lbs
TDC12S4BMC 480Vac, 3A, 1PH/3PH*
TDC12X1BMC 120Vac, 10A, 1PH; 240Vac, 5A, 1PH/3PH*
Extended
Cycle
TDC12X4BMC 480Vac, 3.5A, 1PH/3PH*
TDC22X1BMC 120/240 single, 3 phase*
2200 lbs
TDC22X4BMC 480V 3 phase*
JHDC12X1N4XMC
Hoist Nema4X
Operators
120/240 single, 3 phase N4X
Extended
Cycle
1200 lbs
JHDC12X4N4XMC 480V 3 phase N4X
JHDC22X1N4XMC 120/240 single, 3 phase
2200 lbs
JHDC22X4N4XMC 480V 3 phase
TDC12X1N4XMC
Trolley Nema4X
Operators
120/240 single, 3 phase N4X
Extended
Cycle
1200 lbs
TDC12X4N4XMC 480V 3 phase N4X
TDC22X1N4XMC 120/240 single, 3 phase N4X
2200 lbs
TDC22X4N4XMC 480V 3 phase N4X
* BBU capable
** BBU included
