Chamberlain JDC - Model JHDC; Model TDC, JDC, and JHDC Common Parts

68
Service Parts
Model JHDC
SERVICE KITS
Item Part # Description
190925FT12 Hoist Chain
K41-0269-000 Disengage Rope (red), Engage
Rope (green), two screws
15-50B12LGH Drive Sprocket
Model TDC, JDC, and JHDC Common Parts
SERVICE KITS
Item Part # Description Item Part # Description
K41-0374-000 24 DC Motor, Gear Box &
Encoder (Jack Shaft 700)
K41-0394-000 EMI Board 2200 (480Vac)
K41-0375-000 24 DC Motor, Gear Box &
Encoder (Jack Shaft 1200)
K41-0395-000 Control Box with Cover
K41-0376-000 24 DC Motor, Gear Box &
Encoder (Jack Shaft 2200)
K41-0380-000 Bridge Rectier 700/1200
K41-0377-000 24 DC Motor, Gear Box &
Encoder (Trolley 700)
TBD Bridge Rectier 2200
K41-0378-000 24 DC Motor, Gear Box &
Encoder (Trolley 1200)
K41-0381-000 Toroidal Transformer
700Lb/120Vac-240VAC
K41-0379-000 24 DC Motor, Gear Box &
Encoder (Trolley 2200)
K41-0382-000 Toroidal Transformer
700Lb/480VAC
K41-0409-000 1200 Extended duty Motor, Gear
Box & Encoder Trolley
K41-0383-000 Toroidal Transformer
1200Lb/120Vac-240VAC
K41-0410-000 1200 Extended duty Motor, Gear
Box & Encoder Hoist
K41-0384-000 Toroidal Transformer
1200Lb/480VAC
K41-0388-000 Main board (with Battery Backup) K41-0385-000 Toroidal Transformer
2200Lb/120Vac-240VAC
K41-0389-000 EMI Board 700 (120VAC 240VAC) K41-0386-000 Toroidal Transformer
2200Lb/480VAC
K41-0390-000 EMI Board 700 (480Vac) K77-36541 Antenna
K41-0391-000 EMI Board 1200 (120VAC
240VAC)
K41-0387-000 Encoder (with drive sprocket,
snap ring, mounting plate,
screws)
K41-0392-000 EMI Board 1200 (480Vac) TBD Brake 24VDC (for 2200
operators)
K41-0393-000 EMI Board 2200 (120VAC
240VAC)
