Chamberlain JDC - Programmable Inputs; Radio; Programming Remote Controls and Myq Devices; Erasing Programmed Devices

42
Programming (continued)
Programmable Inputs
• The controller contains three programmable inputs
that may be congured to accept several dierent
input devices.
• Navigate through the menus to SYSTEM SETTINGS
(enter password) to PROG INPUTS. Select INP1,
INP2 or INP3.
• Select a Function from the list. Press Enter.
• Select a Polarity from the list. Press Enter.
Function Options:
• Non-monitored Eye/Edge Input
• Car Dealer Input (typically loop detector, treadle
hose, card reader)
• Timer Defeat
• All Fly (previously known as FSTS)
Radio
The controller has a built in Security+ 2.0® radio receiver,
that can program up to 90 remote control devices and up
to 30 keyless entry devices.
Programming Remote Controls
and myQ® Devices
1. Select SYSTEM SETTINGS from the main menu
(enter passcode.)
2. Select CONNECTIVITY.
3. Select one of: Learn myQ Devices, Wi-Fi, or
Remotes.
4. The operator will indicate the selected accessory is
being learned.
5. Repeat as needed for any other devices and
remotes.
Erasing Programmed Devices
1. Select Connectivity from the main menu (enter
passcode).
2. Select Erase.
3. Select the type of device to be erased or select
"Erase all".
4. Press "UP" button to erase the selected device.
5. Display will conrm erasing selected device.
Reset Defaults
Parameter Default Value
Operating Mode B2
Frequency Prole Maximum Speed
Open Frequency 10HZ
Close Frequency 10HZ
Limits Must Relearn Limits
Timer to Close 120 sec.
Delay to Open 0
Delay to Close 0
INP1 Function No Function
INP1 Logic N.O.
INP2 Function No Function
INP2 Logic N.O.
INP3 Function No Function
INP3 Logic N.O.
Eye/Edge Unlearned
Service Counter Interval 5000
Service Counter Value Is not reset
Absolute Cycle Counter Is not reset
NOTICE: This device complies with part 15 of the FCC rules and
Innovation, Science and Economic Development Canada license-
exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that
may cause undesired operation.
Any changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
This device must be installed to ensure a minimum 20 cm (8 in.)
distance is maintained between users/bystanders and device.
This device has been tested and found to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC rules and
Industry Canada ICES standard. These limits are designed to provide
reasonable protection against harmful interference in a commercial
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
