Chamberlain JDC - Accessories

63
Accessories
ENTRAPMENT PROTECTION DEVICES
(MONITORED)
CPS-U - Dual-Sided Infrared Photoelectric Sensors
• NEMA 1 general purpose
enclosure.
• Dual-sided infrared sensors.
• For indoor use.
• Maximum range of 30 feet (9.1 m).
(CPS-UN4)
(CPS-U)
(CPS-RPEN4)
(CPS-OPEN4)
Optical Edge System (OES)
(CPS3CARD)
LMTBUL - Monitored Thru-Beam Photoelectric Sensors
• Max Range: 90 ft. (27.4 m)
• Cable Length: 10 ft. (3 m)
• Operating Temperature: -40°C to 65°C
(-40°F to 149°F)
• Outdoor Rating: Nema 4X
• Heater: Thermostatically controlled
• Input Voltage:
• Sensor: Black/red wires 6.8 VDC, 20mA
• Heater: Green/white wires 10-40VDC or 8-28 VAC, 4
watts max., 170mA per pair @ 24 VDC/VAC, 340mA
per pair @ 12 VDC/VAC
LMRRUL - Monitored Retro-Reective Photoelectric
Sensors
• Max Range: 50 ft. (15.2 m)
• Cable Length: 10 ft. (3 m)
• Operating Temperature: -40°C to 65°C
(-40°F to149°F)
• Outdoor Rating: Nema 4X
• Heater: Thermostatically controlled
• Input Voltage:
• Sensor: Black/red wires 6.8 VDC, 20mA
• Heater: Green/white wires 10-40VDC or 8-28 VAC, 4
watts max., 170mA per pair @ 24 VDC/VAC, 340mA
per pair @ 12 VDC/VAC
CPS-UN4 - Monitored Thru-Beam Photoelectric
Sensors
• Heavy-duty housing for industrial
applications.
• NEMA 4 enclosure protects against
direct spray.
• Dual-sided infrared sensors.
• For indoor/outdoor use.
• Maximum range of 45 feet (13.7 m).
(CPS-UN4)
(CPS-U)
(CPS-RPEN4)
(CPS-OPEN4)
Optical Edge System (OES)
(CPS3CARD)
CPS-RPEN4 - Monitored Retro-Reective Photoelectric
Sensors
• Polarized reector for use in applications
with highly reective surfaces.
• NEMA 4X enclosure protects against
direct water spray and corrosion.
• Retro-reective sensor.
• For indoor/outdoor use.
• Maximum range of 50 feet (15 m).
(CPS-UN4)
(CPS-U)
(CPS-RPEN4)
(CPS-OPEN4)
Optical Edge System (OES)
(CPS3CARD)
CPS-OPEN4 - Monitored Dual-Sided Photoelectric
Sensors
• Flexible housings maintain alignment in
areas with a high propensity for sensor
contact.
• NEMA 4X enclosure protects against
direct water spray and corrosion.
• Dual-sided infrared sensors.
• For indoor/outdoor use.
• Maximum range of 45 feet (13.7 m).
(CPS-UN4)
(CPS-U)
(CPS-RPEN4)
(CPS-OPEN4)
Optical Edge System (OES)
(CPS3CARD)
LMWEKITU - Wireless Edge Kit
• Long range Bluetooth® communication
provides up to 130 ft. range
• Accepts up to 4 transmitters, 2 wired
edges per transmitter
• Approved for US/ CAN/ MX, Puerto
Rico, Columbia, Costa Rica
• Meets UL325 requirements
LMWETXU - Wireless Edge Kit
• Long range Bluetooth® communication
provides up to 130 ft. range
• Accepts up to 4 transmitters, 2 wired
edges per transmitter
• Approved for US/ CAN/ MX, Puerto
Rico, Columbia, Costa Rica
• Meets UL325 requirements
OES-SD16 - Optical Edge System
16 feet (4.9 m) Sectional 2-Wire Door
Edge Kit with infrared optical sensors,
rubber door edge and all mounting
hardware (channel sold separately).
(CPS-UN4)
(CPS-U)
(CPS-RPEN4)
(CPS-OPEN4)
Optical Edge System (OES)
(CPS3CARD)
OES-SD24 - Optical Edge System
24 feet (7.3 m) Sectional 2-Wire Door
Edge Kit with infrared optical sensors,
rubber door edge and all mounting
hardware (channel sold separately).
(CPS-UN4)
(CPS-U)
(CPS-RPEN4)
(CPS-OPEN4)
Optical Edge System (OES)
(CPS3CARD)
OES-RD16 - Optical Edge System
16 feet (4.9 m) Rolling 2-Wire Door Edge
Kit with infrared optical sensors, rubber
door edge and all mounting hardware
(door channel not required).
(CPS-UN4)
(CPS-U)
(CPS-RPEN4)
(CPS-OPEN4)
Optical Edge System (OES)
(CPS3CARD)
Optical Edge System (OES)
• Rubber door edge is durable, exible and easy to
install.
• Premium rubber can be cut to length for exact t.
• NEMA 6 rating protects against moisture and
standing water.
• Infrared optical sensors eliminate the need for
electrical contacts.
• Maximum range of 33 feet (10 m).
• Sectional and rolling door edges are also available
in 50 foot (15 m) bulk rolls, along with individual
components for additional savings on large
installation jobs.
S50, L50 - Monitored Edge Sensors
L50, L50E, S50, S50E
CPS-EI - Edge Interface 4-Wire Monitored
For use with approved 4-wire sensing edges listed on this
Accessory page.
ASO Monitored 4-Wire, 2-Wire Sentir Series 45.30
1502.2015, 1502.2014
ASO Monitored 4-Wire, 2-Wire Sentir Series 35.55
1502-2990, 1502-2993, 1502-2991, 1502-2994, 1502-2992,
1502-2995
LC36M - Monitored Light Curtain
Monitored, primary entrapment
protection device that forms a
3-foot cross pattern of invisible light
beams for maximum personnel and
property protection.
ENROLL
FAIL
RETRY
SEND
PASS
READY
ENROLL
