Programming (continued)
WIRING TYPE DEVICE ACTION STATE RESPONSE
TS (continued)
3-Button
Remote Control
Programmed
as OPEN/
CLOSE/STOP
OPEN button
is pressed
momentarily
Operator at OPEN limit No change in state (Recycle TTC)
Operator at CLOSE limit
Door opens to the OPEN limit or Mid-Stop
and activates TTC
Door opening No change in state
Door closing
Door will auto reverse to OPEN limit or Mid-
Stop and activates TTC
Door at Open Mid-Stop
Door opens to the OPEN limit and activates
TTC
Door stopped during open or
close cycle
Door opens to the OPEN limit or Mid-Stop
and activates TTC
CLOSE button
is pressed
momentarily
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes to the CLOSE limit
Door stopped during open or
close cycle
Door closes to the CLOSE limit
STOP button
is pressed
momentarily
Operator at OPEN limit No change in state (Recycle TTC)
Operator at CLOSE limit No change in state
Door opening Door stops and activates TTC
Door closing Door stops and activates TTC
Door at Open Mid-Stop No change in state (Recycle TTC)
Door stopped during open or
close cycle
No change in state (Recycle TTC)
Single Button
Remote Control
Programmed
as SBC
Button is pressed
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit
Door opens to the OPEN limit or Mid-Stop
and activates TTC
Door opening Door stops and activates TTC
Door closing
Door will auto reverse to OPEN limit or Mid-
Stop and activates TTC
Door at Open Mid-Stop
Door opens to the OPEN limit and activates
TTC
Door stopped during the open
cycle
Door closes to the CLOSE limit
Door stopped during the close
cycle
Door opens to the OPEN limit or Mid-Stop
and activates TTC
Single Button
Wall Controller
(Wired)
Button is pressed
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit
Door opens to the OPEN limit or Mid-Stop
and activates TTC
Door opening Door stops and activates TTC
Door closing
Door will auto reverse to OPEN limit or Mid-
Stop and activates TTC
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during the open
cycle
Door closes to the CLOSE limit
Door stopped during the close
cycle
Door opens to the OPEN limit or Mid-Stop
and activates TTC
Button is held
(constant
pressure)
Door opening
No change in state or Mid-Stop and activates
TTC
myQ® Smart
Facility Access
Open is pressed
Operator at OPEN limit No change in state (Recycle TTC)
Operator at CLOSE limit
Door opens to the OPEN limit or Mid-Stop
(activates TTC)
Door opening No change in state
Door closing
Door will auto reverse to OPEN limit or Mid-
Stop and activates TTC
Door at Open Mid-Stop
Door opens to the OPEN limit and activates
TTC
Door stopped during open or
close cycle
Door opens to the OPEN limit or Mid-Stop
and activates TTC
Close is pressed
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes to the CLOSE limit
Door stopped during open or
close cycle
Door closes to the CLOSE limit
