Programming (continued)
WIRING TYPE DEVICE ACTION STATE RESPONSE
T (continued)
Single
Button Wall
Controller
(Wired)
Button is
pressed
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit Door opens to the OPEN limit or Mid-Stop
Door opening Door stops
Door closing
Door will auto reverse to OPEN limit or Mid-Stop
and activates TTC
Door at Open Mid-Stop Door opens to the OPEN limit and activates TTC
Door stopped during the open cycle Door closes to the CLOSE limit
Door stopped during the close cycle
Door opens to the OPEN limit or Mid-Stop and
activates TTC
Button is held
(constant
pressure)
Door opening No change in state
myQ®
Smart
Facility
Access
Open is
pressed
Operator at OPEN limit No change in state (Recycle timer)
Operator at CLOSE limit
Door opens to the OPEN limit or Mid-Stop and
activates TTC
Door opening No change in state
Door closing
Door will auto reverse to OPEN limit or Mid-Stop
and activates TTC
Door at Open Mid-Stop Door opens to the OPEN limit and activates TTC
Door stopped during open or close
cycle
Door opens to the OPEN limit or Mid-Stop and
activates TTC
Close is
pressed
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes to the CLOSE limit
Door stopped during open or close
cycle
Door closes to the CLOSE limit
WIRING TYPE DEVICE ACTION STATE RESPONSE
TS -
This mode will attempt
to close the door from
any position except
when fully closed, or
when a safety input
is present. The stop
button will recycle the
Timer-To-Close (TTC) at
any position. To disable
the TTC in this mode,
installation of a defeat
switch is required (see
wiring diagram).
Momentary contact to
open, close, and stop
with open override and
TTC. Every device that
causes door to open,
including a reversing
device, activates the
TTC. Auxiliary controls
can be connected to
open input to activate
the TTC. If the timer
has been activated, the
open button and radio
control can recycle
the timer. The TTC will
function from the Open
limit and Open mid
stop with this operating
mode type. Close Mid
Stop available but not
shown in table.
Compatible with
3-Button Station,
1-Button Station and 1
and 3-Button Remote
Control.
Monitored Entrapment
Protection (LMEP)
Device required.
Front panel
buttons
(membrane)
and
3-Button
Wall
Controller
OPEN
button is
pressed
momentarily
Operator at OPEN limit No change in state (Recycle TTC)
Operator at CLOSE limit
Door opens to the OPEN limit or Mid-Stop
and activates TTC
Door opening No change in state
Door closing
Door will auto reverse to OPEN limit or Mid-
Stop and activates TTC
Door at Open Mid-Stop
Door opens to the OPEN limit and activates
TTC
Door stopped during open or close cycle
Door opens to the OPEN limit or Mid-Stop
and activates TTC
CLOSE
button is
pressed
momentarily
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes to the CLOSE limit
Door stopped during open or close cycle Door closes to the CLOSE limit
STOP
button is
pressed
momentarily
Operator at OPEN limit No change in state (Recycle TTC)
Operator at CLOSE limit No change in state
Door opening Door stops and activates TTC
Door closing Door stops and activates TTC
Door at Open Mid-Stop No change in state (Recycle TTC)
Door stopped during open or close cycle No change in state (Recycle TTC)
OPEN
button
is held
(constant
pressure)
Operator at OPEN limit No change in state (Recycle & hold TTC)
Operator at CLOSE limit
Door opens to the OPEN limit (bypasses
Mid-Stop) and activates TTC
Door opening
No change in state (bypasses Mid-Stop)
and activates TTC
Door closing
Door will auto reverse to OPEN limit
(bypasses Mid-Stop) and activates TTC
Door at Open Mid-Stop
Door opens to the OPEN limit and activates
TTC
Door stopped during open or close cycle
Door opens to the OPEN limit (bypasses
Mid-Stop) and activates TTC
CLOSE
button
is held
(constant
pressure)
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes to the CLOSE limit
Door stopped during open or close cycle Door closes to the CLOSE limit
