Programming (continued)
WIRING
TYPE
DEVICE ACTION STATE RESPONSE
T -
Momentary
contact to
open, close,
and stop, with
open override
and Timer-To-
Close (TTC).
Every device
that causes the
door to open,
except any
sensing edge
input device,
activates the
TTC. Auxiliary
controls can be
connected to
open input to
activate the TTC.
If the TTC has
been activated,
the open button
and radio control
can recycle
the timer. The
stop button will
deactivate the
timer until the
next command
input. The TTC
will function
from the Open
limit stop and
Open Mid-Stop
available with
this mode type.
Compatible
with 3-Button
Station, 1-Button
Station and 1
and 3-Button
Remote Control.
Close Mid-Stop
is available but
not shown in
table.
Monitored
Entrapment
Protection
(LMEP) Device
required.
Front panel
buttons
(membrane)
and 3-Button
Wall
Controller
OPEN
button is
pressed
momentarily
Operator at OPEN limit No change in state (Recycle timer)
Operator at CLOSE limit
Door opens to the OPEN limit or Mid-Stop (and
activates TTC)
Door opening No change in state
Door closing
Door will auto reverse to OPEN limit or Mid-Stop
(and activates TTC)
Door at Open Mid-Stop
Door opens to the OPEN limit (and activates
TTC)
Door stopped during open or close cycle
Door opens to the OPEN limit or Mid-Stop (and
activates TTC)
CLOSE
button is
pressed
momentarily
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes to the CLOSE limit
Door stopped during open or close cycle Door closes to the CLOSE limit
STOP button
is pressed
momentarily
Operator at OPEN limit No change in state (Deactivate timer)
Operator at CLOSE limit No change in state
Door opening Door stops
Door closing Door stops
Door at Open Mid-Stop No change in state (Deactivate timer)
Door stopped during open or close cycle No change in state
OPEN
button
is held
(constant
pressure)
Operator at OPEN limit No change in state (Recycle & hold timer)
Operator at CLOSE limit
Door opens to the OPEN limit (bypasses Mid-
Stop) and activates TTC
Door opening No change in state (bypasses Mid-Stop)
Door closing
Door will auto reverse to OPEN limit (bypasses
Mid-Stop) and activates TTC
Door at Open Mid-Stop Door opens to the OPEN limit and activates TTC
Door stopped during open or close cycle
Door opens to the OPEN limit (bypasses Mid-
Stop) and activates TTC
CLOSE
button
is held
(constant
pressure)
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes to the CLOSE limit
Door stopped during open or close cycle Door closes to the CLOSE limit
3-Button
Remote
Control
Programmed
as OPEN/
CLOSE/
STOP
OPEN
button is
pressed
momentarily
Operator at OPEN limit No change in state (Recycle timer)
Operator at CLOSE limit
Door opens to the OPEN limit or Mid-Stop and
activates TTC
Door opening No change in state
Door closing
Door will auto reverse to OPEN limit or Mid-Stop
and activates TTC
Door at Open Mid-Stop Door opens to the OPEN limit and activates TTC
Door stopped during open or close cycle
Door opens to the OPEN limit or Mid-Stop and
activates TTC
CLOSE
button is
pressed
momentarily
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes to the CLOSE limit
Door stopped during open or close cycle Door closes to the CLOSE limit
STOP button
is pressed
momentarily
Operator at OPEN limit No change in state (Deactivate timer)
Operator at CLOSE limit No change in state
Door opening Door stops
Door closing Door stops
Door at Open Mid-Stop No change in state (Deactivate timer)
Door stopped during open or close cycle No change in state
Single Button
Remote
Control
Programmed
as SBC
Button is
pressed
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit
Door opens to the OPEN limit or Mid-Stop and
activates TTC
Door opening Door stops
Door closing
Door will auto reverse to OPEN limit or Mid-Stop
and activates TTC
Door at Open Mid-Stop Door opens to the OPEN limit and activates TTC
Door stopped during the open cycle Door closes to the CLOSE limit
Door stopped during the close cycle
Door opens to the OPEN limit or Mid-Stop and
activates TTC
