Chamberlain JDC - Page 38

38
Programming (continued)
WIRING
TYPE
DEVICE ACTION STATE RESPONSE
D1 -
Constant
pressure to
open and
close with
wiring for
sensing
device to
stop.
Compatible
with 2 or
3-Button
Station
3-Button
Wall
Controller
OPEN button is
pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit Door opens and stops when button is released
Door opening No change in state
Door closing Door stops
Door at Open Mid-Stop Door opens and stops when button is released
Door stopped during open or close cycle Door opens and stops when button is released
CLOSE button
is pressed
momentarily
Operator at OPEN limit Door closes and stops when button is released
Operator at CLOSE limit No change in state
Door opening Door stops
Door closing No change in state
Door at Open Mid-Stop Door closes and stops when button is released
Door stopped during open or close cycle Door closes and stops when button is released
STOP button is
pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening Door stops
Door closing Door stops
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle Door stops only in the closed position
OPEN button is
held (constant
pressure)
Operator at OPEN limit No change in state
Operator at CLOSE limit Door opens to the OPEN limit
Door opening No change in state
Door closing Door stops
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during open or close cycle Door stops only in the closed position
CLOSE
button is held
(constant
pressure)
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes to the CLOSE limit
Door stopped during open or close cycle Door stops only in the open position
3-Button
Remote
Control
Programmed
as OPEN /
CLOSE /
STOP
Not all
transmitters
will give
constant
pressure to
close
OPEN button is
pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle No change in state
CLOSE button
is pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle No change in state
STOP button is
pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle No change in state
Single Button
Remote
Control
Button is
pressed
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle No change in state
Single
Button Wall
Controller
(Wired)
Button is
pressed:
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during the open cycle No change in state
Door stopped during the close cycle No change in state
myQ
Door image is
pressed:
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle No change in state
