Chamberlain JDC - Page 37

37
Programming (continued)
WIRING
TYPE
DEVICE ACTION STATE RESPONSE
E2 -
Momentary
contact to
open with
override
and
constant
pressure
to close.
Release
of close
button will
cause door
to reverse
(roll-back
feature)
plus wiring
for sensing
device to
reverse.
Compatible
with
3-Button
Station.
3-Button
Wall
Controller
OPEN
button is
pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit Door opens to the OPEN limit or Mid-Stop
Door opening No change in state
Door closing Door will auto reverse to OPEN limit or Mid-Stop
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during open or close cycle Door opens to the OPEN limit or Mid-Stop
CLOSE
button is
pressed
momentarily
Operator at OPEN limit Door closes and auto reverses when button is released
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes and auto reverses when button is released
Door stopped during open or close cycle Door closes and auto reverses when button is released
STOP
button is
pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening Door stops
Door closing Door stops
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle No change in state
OPEN
button
is held
(constant
pressure)
Operator at OPEN limit No change in state
Operator at CLOSE limit Door opens to the OPEN limit (bypasses Mid-Stop)
Door opening No change in state (bypasses Mid-Stop)
Door closing Door will auto reverse to OPEN limit (bypasses Mid-
Stop)
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during open or close cycle Door opens to the OPEN limit (bypasses Mid-Stop)
CLOSE
button
is held
(constant
pressure)
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes and auto reverses when button is released
Door stopped during open or close cycle Door closes and auto reverses when button is released
3-Button
Remote
Control
Programmed
as OPEN/
CLOSE/
STOP
OPEN
button is
pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit Door opens to the OPEN limit or Mid-Stop
Door opening No change in state
Door closing Door will auto reverse to OPEN limit or Mid-Stop
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during open or close cycle Door opens to the OPEN limit or Mid-Stop
CLOSE
button is
pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle No change in state
STOP
button is
pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening Door stops
Door closing Door stops
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle No change in state
Single
Button
Remote
Control
Button is
pressed
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle No change in state
Single
Button Wall
Controller
(Wired)
Button is
pressed:
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during the open cycle No change in state
Door stopped during the close cycle No change in state
myQ
Door image
is pressed:
Operator at OPEN limit No change in state
Operator at CLOSE limit Door opens to the OPEN limit
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle No change in state
