36
Programming (continued)
WIRING
TYPE
DEVICE
ACTION
STATE RESPONSE
C2 (continued)
3-Button
Remote Control
Programmed as
OPEN/CLOSE/
STOP
OPEN button
is pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit Door opens to the OPEN limit or Mid-Stop
Door opening No change in state
Door closing Door will auto reverse to OPEN limit or Mid-Stop
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during open or
close cycle
Door opens to the OPEN limit or Mid-Stop
CLOSE button
is pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during open or
close cycle
No change in state
STOP button
is pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening Door stops
Door closing Door stops
Door at Open Mid-Stop No change in state
Door stopped during open or
close cycle
No change in state
Single Button
Remote Control
Programmed
as SBC
Button is
pressed
Operator at OPEN limit No change in state
Operator at CLOSE limit Door opens to the OPEN limit or Mid-Stop
Door opening Door stops
Door closing Door will auto reverse to OPEN limit or Mid-Stop
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during open cycle No change in state
Door stopped during close cycle Door opens to the OPEN limit or Mid-Stop
Single Button
Wall Controller
(Wired)
Button is
pressed
Operator at OPEN limit Door closes and stops when button is released
Operator at CLOSE limit Door opens to the OPEN limit or Mid-Stop
Door opening Door stops
Door closing Door will auto reverse to OPEN limit or Mid-Stop
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during open cycle Door closes and stops when button is released
Door stopped during close cycle Door opens to the OPEN limit or Mid-Stop
Button is held
(constant
pressure)
Door Opening No change in state or Mid-Stop
myQ
®
Smart
Facility Access
Open is pressed
Operator at OPEN limit No change in state
Operator at CLOSE limit Door opens to the OPEN limit or Mid-Stop
Door opening No change in state
Door closing Door will auto reverse to OPEN limit or Mid-Stop
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during open or
close cycle
Door opens to the OPEN limit or Mid-Stop
Close is pressed
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop No change in state
Door stopped during open or
close cycle
No change in state
