Programming (continued)
WIRING
TYPE
DEVICE
ACTION
STATE RESPONSE
B2 (continued)
Single
Button Wall
Controller
(Wired)
Button is pressed
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit Door opens to the OPEN limit or Mid-Stop
Door opening Door stops
Door closing
Door will auto reverse to OPEN limit or
Mid-Stop
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during the open cycle Door closes to the CLOSE limit
Door stopped during the close cycle Door opens to the OPEN limit or Mid-Stop
Button is held
(constant pressure)
Door Opening No change in state (bypasses Mid-Stop)
myQ
®
Smart
Facility
Access
Open is pressed
Operator at OPEN limit No change in state
Operator at CLOSE limit Door opens to the OPEN limit or Mid-Stop
Door opening No change in state
Door closing
Door will auto reverse to OPEN limit or
Mid-Stop
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during open or close cycle Door opens to the OPEN limit or Mid-Stop
Close is pressed:
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes to the CLOSE limit
Door stopped during open or close cycle Door closes to the CLOSE limit
WIRING
TYPE
DEVICE
ACTION
STATE RESPONSE
C2
Momentary
contact to
open and stop
with constant
pressure to
close (wired
devices ONLY),
open override
plus wiring for
sensing device
to reverse.
Open Mid-Stop
available with
this mode type.
Compatible
with 3-Button
Station and
Single-Button
Station
Front panel
buttons
(membrane)
and 3-Button
Wall
Controller
OPEN button
is pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit
Door opens to the OPEN limit or Mid-
Stop
Door opening No change in state
Door closing
Door will auto reverse to OPEN limit or
Mid-Stop
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during open or close cycle
Door opens to the OPEN limit or Mid-
Stop
CLOSE button
is pressed
momentarily
Operator at OPEN limit
Door closes and stops when button is
released
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop
Door closes and stops when button is
released
Door stopped during open or close cycle
Door closes and stops when button is
released
STOP button
is pressed
momentarily
Operator at OPEN limit No change in state
Operator at CLOSE limit No change in state
Door opening Door stops
Door closing Door stops
Door at Open Mid-Stop No change in state
Door stopped during open or close cycle No change in state
OPEN button is held
(constant pressure)
Operator at OPEN limit No change in state
Operator at CLOSE limit
Door opens to OPEN limit (bypasses
Mid-Stop)
Door opening No change in state (bypasses Mid-Stop)
Door closing
Door will auto reverse to OPEN limit
(bypasses Mid-Stop)
Door at Open Mid-Stop Door opens to the OPEN limit
Door stopped during open or close cycle
Door opens to the OPEN limit (bypasses
Mid-Stop)
CLOSE button is
held (constant
pressure)
Operator at OPEN limit Door closes to the CLOSE limit
Operator at CLOSE limit No change in state
Door opening No change in state
Door closing No change in state
Door at Open Mid-Stop Door closes to the CLOSE limit
Door stopped during open or close cycle Door closes to the CLOSE limit
