Dishwasher Construction
Dishwasher Construction
1. The Upright Conveyor dishwasher, (also called the ight-type conveyor), is assembled
as a single unit from sections or modules.
2. This basic design is then customized to the customer's specications.
3. The information presented blow explains the basic construction of the upright conveyor
dishwasher. It does not cover custom-built innovations.
4. Study the diagrams on the next page, then continue reading below.
Dishwasher Sections:
Five sections make up the basic assembly. The sections are:
Load, Prewash, Wash, Rinse,
Final rinse, Unload
Dishwasher Views:
Plan View
Elevation
Side View
To Next Page
