Champion Eseries - Page 115

107
Fill Piping - No Booster (Prior to S/N J10012728)
1 100184 NIPPLE, 3/4" NPT X CLOSE BRASS 4
2 102392 BUSHING, REDUCING, 3/4" NPT X 1/2" NPT BRASS 1
3 102504 PLUG, 1/2" NPT SQ. HEAD BRASS 1
4 102521 TEE, 3/4" NPT BRASS 1
5 102526 TEE, RED, 3/4" X 3/4" X 1/2" NPT BRASS 1
6 107550 VALVE, PRESSURE REGULATING, 3/4" NPT BRONZE
1
7 107967 HEX GRIP NUT, 1/4-20 SST W/NYLON
2
8 109926 FITTING, COMP. 5/8" OD X 1/2" MNPT, ELL BRASS 1
9 109879 FITTING, COMP. 7/8" OD X 3/4" MPT BRASS 1
10 110768 STRAINER, LINE 3/4" NPT BRONZE FEMALE 1
11 111437 VALVE, SOLENOID 3/4" NPT HW, 115VAC 1
--- 114839 KIT, REPAIR, 3/4" SOLENOID VALVE
A
/R
--- 111472 COIL, SOLENOID 3/4" 115VAC
A
/R
12 A511-8 BRACKET, 3/4" PIPE 2
