129
Steam Coil Heat Installation Auxiliary,15-30 PSI
(Parts list continued on next page)
1 100007 SCREW,TRUSS HEAD,10-32 x 3/8 SST3
2 100051 NIPPLE,3/4"NPT X CLOSE,SST2
3 100109 WELD-STUD,1/4-20 X 1/2 LG.SST 2
4 100134 ELBOW,STREET,1NPT X 90,MI2
5A 102288 ELBOW,1/2NPT X 90,MI EUCC 3
5 100147 ELBOW,STREET,1/2NPT X 90,MI3
6 100154 HEX PLAIN NUT,5/16-18 SST8
7 100198 WELD-STUD,10-32 X 1/2 LG.SST 4
8 100547 LOCKNUT,1/2" NPT,SST1
9 100740 HEX HEAD,5/16-18 X 1 SST8
10 102376 WASHER,FLAT,5/16x3/4x.06 SST16
11 102506 PLUG,3/4"NPT SQ.HEAD,SST2
12 102554 UNION,3/4"NPT, SST2
13 105738 ELBOW,REDUCING,3/4"NPT X 1/2"NPT X 90,M.I.1
14 105739 ELBOW,REDUCING,1"NPT X 3/4"NPT X 90,M.I.1
15 105778 UNION,1/2"NPT, MALLEABLE IRON2
16 105780 UNION,1"NPT, MALLEABLE IRON2
17 105782 NIPPLE,1/2"NPT X CLOSE.,B.I.1
18 105783 NIPPLE,1/2"NPT X 2" LG.,B.I.1
19 105785 NIPPLE,1/2"NPT X 2 1/2" LG.,B.I. EUCCW 1
20 105847 NIPPLE,1"NPT X CLOSE,B.I.
NIPPLE,1"NPT X CLOSE,B.I. EUCC
NIPPLE,1"NPT X CLOSE,B.I. EUCC
1
21 105854 NIPPLE,1"NPT X 3 1/4" LG.,B.I.1
5B 107488 NIPPLE,1/2NPT X 3-1/2" LG. B.I. EUCC3
--- 105782 1
--- 105847 1
22 105863 NIPPLE,1"NPT X 6 1/2" LG.,B.I.1
23 106013 WASHER,LOCK,5/16 SPLIT,SST 8
